ATI · 2006
Radeon X1650 XT
The Radeon X1650 XT is a mid-range graphics card released by ATI in October 2006, based on the R500 architecture and RV560 GPU.
The Radeon X1650 XT is a mid-range graphics card from ATI, launched on October 30, 2006. It is built on the R500 architecture using the RV560 GPU manufactured on an 80 nm process. The card features 24 shading units, a base clock of 525 MHz, and 256 MB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 22.4 GB/s. It supports DirectX 9.0c and OpenGL 2.1, and connects via PCIe x16. With a TDP of 55 W, it was positioned as an affordable upgrade for gamers, with a launch MSRP of $149 USD.
Specifications
| Architecture unverified | R500 |
|---|---|
| GPU chip unverified | RV560 |
| Process node unverified | 80 nm |
| Shading units unverified | 24 |
| Base clock unverified | 525 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 22.4 GB/s |
| Board power (TDP) unverified | 55 W |
| Bus interface unverified | PCIe x16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2006-10-30 |
| Release year unverified | 2006 |
| Launch MSRP unverified | 149 USD |
