ATI · 2005
Radeon X1800 XL
The ATI Radeon X1800 XL is a 2005 graphics card featuring the R520 GPU, 256 MB GDDR3 memory, and a 256-bit bus.
The ATI Radeon X1800 XL is a graphics card released by ATI in October 2005 as part of the X1800 series. It is built on the R520 GPU using a 90 nm manufacturing process with a core clock of 500 MHz. The card comes with 256 MB of GDDR3 memory on a 256-bit bus, providing a memory bandwidth of 32.0 GB/s. It uses a PCIe ×16 interface and has a board power (TDP) of 70 W. It supports DirectX 9.0c and OpenGL 2.1. At launch, the Radeon X1800 XL had a suggested retail price of 449 USD. It was designed for use with compatible PCIe ×16 motherboards and power supplies that can deliver the required 70 W.
Specifications
| GPU chip unverified | R520 |
|---|---|
| Process node unverified | 90 nm |
| Base clock unverified | 500 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 32.0 GB/s |
| Board power (TDP) unverified | 70 W |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2005-10-05 |
| Release year unverified | 2005 |
| Launch MSRP unverified | 449 USD |
