ATI · 2005
Radeon X700
The Radeon X700 is a mid-range graphics card released by ATI in September 2005, based on the RV410 GPU and built on a 110 nm process.
The Radeon X700 is a mid-range graphics card from ATI, launched in September 2005. It uses the RV410 GPU manufactured on a 110 nm process, with a base clock of 400 MHz. The card features 128 MB of DDR memory on a 128-bit bus, providing a memory bandwidth of 11.2 GB/s. It supports DirectX 9.0b and OpenGL 2.0. The Radeon X700 was available with either a PCI-E x16 or AGP 8x bus interface, making it compatible with a range of motherboards from that era.
Benchmarks
| PassMark G3D Mark | 73 |
|---|---|
| PassMark G2D Mark | 248 |
Specifications
| Architecture unverified | Radeon X700 series |
|---|---|
| GPU chip unverified | RV410 |
| Process node unverified | 110 nm |
| Shading units unverified | 8 |
| Base clock unverified | 400 MHz |
| Memory size unverified | 0.128 GB |
| Memory type unverified | DDR |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 11.2 GB/s |
| Board power (TDP) unverified | 31 W |
| Bus interface unverified | PCI-E x16, AGP 8x |
| DirectX support unverified | 9.0b |
| OpenGL support unverified | 2.0 |
| Release date unverified | 2005-09 |
| Release year unverified | 2005 |
