Intel · 2022
Intel Core i9 13900K
The Intel Core i9 13900K is a 24-core desktop processor from Intel's Raptor Lake microarchitecture, released in 2022.
The Intel Core i9 13900K is a high-end desktop processor based on the Raptor Lake microarchitecture, manufactured on Intel's 7 nm process node. It features 24 cores (8 performance cores and 16 efficiency cores) and 32 threads, with a base clock of 3.0 GHz and a boost clock of 5.8 GHz. The processor includes 32 MB of L2 cache and 36 MB of L3 cache. It has a base power of 125 W and a maximum turbo power of 253 W. The chip supports both DDR5-5600 and DDR4-3200 memory across two channels, and includes ECC memory support. Integrated graphics are provided by Intel UHD Graphics 770. The processor uses the FCLGA1700 socket and offers 20 PCIe lanes, supporting PCIe 5.0 and 4.0. It is unlocked for overclocking and supports instruction sets including SSE4.1, SSE4.2, and AVX2. The launch MSRP was $589 USD.
Specifications
| Microarchitecture unverified | Raptor Lake |
|---|---|
| Cores | 24 |
| P-cores | 8 |
| E-cores | 16 |
| Threads | 32 |
| Base clock | 3.0 GHz |
| Boost clock | 5.8 GHz |
| L2 cache (total) | 32 MB |
| L3 cache | 36 MB |
| Process node | 7 nm |
| TDP / base power | 125 W |
| Max turbo power | 253 W |
| Socket | FCLGA1700 |
| Memory support | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
| Memory channels | 2 |
| ECC memory support | Yes |
| Integrated graphics | Intel UHD Graphics 770 |
| PCIe lanes (CPU) | 20 |
| PCIe version | 5.0 and 4.0 |
| Instruction sets | Intel SSE4.1, Intel SSE4.2, Intel AVX2 |
| Unlocked multiplier | Yes |
| Release date | 2022-10-01 |
| Release year | 2022 |
| Launch MSRP | 589 USD |
