Intel · 2017
Intel C422
The Intel C422 is a server chipset for LGA 2066 sockets, released in 2017 on a 22 nm process with 6 W TDP.
The Intel C422 is a server chipset designed for LGA 2066 sockets, released on July 11, 2017. It is built on a 22 nm process with a thermal design power (TDP) of 6 W. The chipset supports DDR4 memory with ECC capability, PCIe 3.0 with 24 lanes, and DMI 3.0. It provides 8 SATA III ports, 10 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. It includes vPro support but lacks Intel Rapid Storage Technology, CPU overclocking, and memory overclocking (XMP/EXPO). The C422 is now discontinued.
Specifications
| Socket unverified | LGA 2066 |
|---|---|
| Platform | Server |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 24 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| ECC memory support | Yes |
| SATA III ports | 8 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Intel Rapid Storage Technology | No |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2017-07-11 |
| Release year | 2017 |
| Notes | Discontinued |
