Intel · 2017
Intel X299
The Intel X299 is a desktop chipset released in 2017, supporting LGA 2066 processors. It offers 24 PCIe 3.0 lanes and 8 SATA III ports.
The Intel X299 is a chipset designed for high-end desktop platforms, introduced in 2017. It uses the LGA 2066 socket and is built on a 22 nm process with a TDP of 6 W. The chipset provides 24 PCIe 3.0 lanes, 8 SATA III ports, and supports up to 10 USB 3.2 Gen 1 and 14 USB 2.0 ports. It features integrated MAC for Ethernet, Intel Rapid Storage Technology, and supports both CPU and memory overclocking (XMP). ECC memory and vPro are not supported. The X299 is paired with Intel Core X-series processors.
Specifications
| Socket unverified | LGA 2066 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 24 |
| DMI version | 3.0 |
| ECC memory support | No |
| SATA III ports | 8 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | Yes |
| vPro support | No |
| CPU overclocking | Yes |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date unverified | 2017-05-30 |
| Release year | 2017 |
