AMD · 2010
AMD FirePro 3D V7800
The AMD FirePro 3D V7800 is a professional graphics card for workstations, released in 2010.
The AMD FirePro 3D V7800 is a professional graphics card based on the TeraScale 2 architecture, featuring the Cypress Pro GL (RV870) GPU built on a 40 nm process. It includes 1440 shading units, a base clock of 700 MHz, and 2 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 128 GB/s. The card has a TDP of 138 W and uses a PCIe 2.1 ×16 interface. It supports DirectX 11.0, OpenGL 4.3, and includes features like UVD2, PowerPlay, and Eyefinity. It is designed for use in professional workstations for CAD, DCC, and other graphics-intensive applications.
Specifications
| Architecture unverified | TeraScale 2 |
|---|---|
| GPU chip unverified | Cypress Pro GL (RV870) |
| Process node unverified | 40 nm |
| Shading units unverified | 1440 |
| Base clock unverified | 700 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 128 GB/s |
| Board power (TDP) unverified | 138 W |
| Bus interface unverified | PCIe 2.1 ×16 |
| DirectX support unverified | 11.0 |
| Vulkan support unverified | N/a |
| OpenGL support unverified | 4.3 |
| Release date unverified | 2010-04-26 |
| Release year unverified | 2010 |
| Notes unverified | UVD2, PowerPlay, Eyefinity |
