NVIDIA Quadro K3100M
The NVIDIA Quadro K3100M is a professional mobile graphics card for workstations, released in 2013.
The NVIDIA Quadro K3100M is a professional mobile graphics card designed for workstation laptops, released on July 23, 2013. It is based on the Kepler architecture and uses the GK104 GPU chip manufactured on a 28 nm process. The card features 768 shading units, a base and boost clock of 680 MHz, and 4 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 102.4 GB/s. It has a TDP of 75 W and connects via PCIe 3.0 x16. It supports DirectX 11.0 and OpenGL 4.5. This card was used in the Dell Precision M6800 mobile workstation.
Specifications
| Architecture unverified | Kepler |
|---|---|
| GPU chip unverified | GK104 |
| Process node unverified | 28 nm |
| Shading units unverified | 768 |
| Base clock unverified | 680 MHz |
| Boost clock unverified | 680 MHz |
| Memory size unverified | 4 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 102.4 GB/s |
| Board power (TDP) unverified | 75 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 11.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2013-07-23 |
| Release year unverified | 2013 |
| Notes unverified | Dell Precision M6800 |
