NVIDIA · 2016
NVIDIA Quadro M500M
The NVIDIA Quadro M500M is a mobile professional graphics card based on the Maxwell architecture, released in 2016.
The NVIDIA Quadro M500M is a mobile professional graphics card released on April 27, 2016. It is built on the Maxwell architecture using the GM108 GPU chip on a 28 nm process. The card features 384 shading units with a base clock of 1029 MHz and a boost clock of 1124 MHz. It is equipped with 2 GB of DDR3 memory on a 64-bit bus, providing a memory bandwidth of 14.40 GB/s. The card has a board power (TDP) of 25 W and connects via a PCIe 3.0 x16 interface. It supports DirectX 12.1, Vulkan 1.3, and OpenGL 4.6. The Quadro M500M is designed for use in mobile workstations, offering certified drivers for professional applications.
Specifications
| Architecture unverified | Maxwell |
|---|---|
| GPU chip unverified | GM108 |
| Process node unverified | 28 nm |
| Shading units unverified | 384 |
| Base clock unverified | 1029 MHz |
| Boost clock unverified | 1124 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | DDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 14.40 GB/s |
| Board power (TDP) unverified | 25 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 12.1 |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2016-04-27 |
| Release year unverified | 2016 |
