NVIDIA Quadro K3000M
The NVIDIA Quadro K3000M is a professional mobile graphics card for laptops, released in 2012 based on the Kepler architecture.
The NVIDIA Quadro K3000M is a professional mobile graphics processing unit introduced in June 2012. It is built on the Kepler architecture using the GK104 chip fabricated on a 28 nm process. The card features 576 shading units, a base and boost clock of 654 MHz, and 2 GB of GDDR5 memory on a 256-bit bus, delivering a memory bandwidth of 89.6 GB/s. It has a TDP of 75 W and connects via PCIe 3.0 x16. It supports DirectX 11.0 and OpenGL 4.5. This GPU was used in the Dell Precision M6700 mobile workstation.
Specifications
| Architecture unverified | Kepler |
|---|---|
| GPU chip unverified | GK104 |
| Process node unverified | 28 nm |
| Shading units unverified | 576 |
| Base clock unverified | 654 MHz |
| Boost clock unverified | 654 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 89.6 GB/s |
| Board power (TDP) unverified | 75 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 11.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2012-06-01 |
| Release year unverified | 2012 |
| Notes unverified | Dell Precision M6700 |
