AMD FirePro R5000
The AMD FirePro R5000 is a professional graphics card released in 2013, based on the GCN 1st generation architecture with a Pitcairn LE GL GPU.
The AMD FirePro R5000 is a workstation graphics card launched on February 25, 2013. It features the GCN 1st generation architecture and the Pitcairn LE GL GPU built on a 28 nm process. The card includes 768 shading units, a base clock of 825 MHz, and 2 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 102.4 GB/s. It has a board power (TDP) of 150 W and connects via PCIe 3.0 ×16. Display outputs consist of two Mini DisplayPorts, and it also includes an Ethernet port with Tera2 PCoIP technology. The card supports DirectX 11.1 and OpenGL 4.5.
Specifications
| Architecture unverified | GCN 1st gen |
|---|---|
| GPU chip unverified | Pitcairn LE GL |
| Process node unverified | 28 nm |
| Shading units unverified | 768 |
| Base clock unverified | 825 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 102.4 GB/s |
| Board power (TDP) unverified | 150 W |
| Bus interface unverified | PCIe 3.0 ×16 |
| Display outputs unverified | 2× Mini DisplayPort |
| DirectX support unverified | 11.1 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2013-02-25 |
| Release year unverified | 2013 |
| Notes unverified | Ethernet port plus 2× Mini DisplayPort with Tera2 PCoIP |
