NVIDIA · 2013
NVIDIA Quadro K5100M
The NVIDIA Quadro K5100M is a professional mobile graphics card released in 2013, based on the Kepler architecture.
The NVIDIA Quadro K5100M is a professional mobile graphics card released on July 23, 2013. It is based on the Kepler architecture and uses the GK104 GPU chip fabricated on a 28 nm process. The card features 1536 shading units, a base and boost clock of 771 MHz, and 8 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 115.2 GB/s. It has a board power (TDP) of 100 W and connects via PCIe 3.0 x16. The K5100M supports DirectX 11.0 and OpenGL 4.5. It was used in the Dell Precision M6800 mobile workstation.
Specifications
| Architecture unverified | Kepler |
|---|---|
| GPU chip unverified | GK104 |
| Process node unverified | 28 nm |
| Shading units unverified | 1536 |
| Base clock unverified | 771 MHz |
| Boost clock unverified | 771 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 115.2 GB/s |
| Board power (TDP) unverified | 100 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 11.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2013-07-23 |
| Release year unverified | 2013 |
| Notes unverified | Dell Precision M6800 |
