AMD · 2015
AMD FirePro W7170M
The AMD FirePro W7170M is a professional mobile graphics card for workstations, released in 2015.
The AMD FirePro W7170M is a professional mobile graphics card released on October 2, 2015. It is based on the GCN 3rd generation architecture and uses the Amethyst XT GPU chip manufactured on a 28 nm process. The card features 2048 shading units, a base clock of 723 MHz, and 4 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 160 GB/s. It has a board power (TDP) of 100 W and connects via PCIe 3.0 x16. The card supports DirectX 12.0 (feature level 11_1), Vulkan 1.0, and OpenGL 4.6. It was used in the Dell Precision 7710 workstation and is an MXM-3-B form factor module.
Specifications
| Architecture unverified | GCN 3rd gen |
|---|---|
| GPU chip unverified | Amethyst XT |
| Process node unverified | 28 nm |
| Shading units unverified | 2048 |
| Base clock unverified | 723 MHz |
| Memory size unverified | 4 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 160 GB/s |
| Board power (TDP) unverified | 100 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 12.0 (feature level 11_1) |
| Vulkan support unverified | 1.0 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2015-10-02 |
| Release year unverified | 2015 |
| Notes unverified | Dell Precision 7710, MXM-3-B |
