AMD · 2015
AMD FirePro W4300
The AMD FirePro W4300 is a professional graphics card for workstations, released in 2015. It features a low-profile design with four Mini DisplayPort outputs.
The AMD FirePro W4300 is a professional graphics card released on December 1, 2015, targeting workstation users. It is based on the GCN 2nd Gen architecture with the Bonaire PRO GPU chip built on a 28 nm process. The card features 768 shading units, a base clock of 930 MHz, and 4 GB of GDDR5 memory on a 128-bit bus, providing a memory bandwidth of 96 GB/s. It has a low board power (TDP) of 50 W and connects via PCIe 3.0 x16. Display outputs include four Mini DisplayPort 1.2a ports. The card supports DirectX 11.2/12.0 with Shader Model 5.0, Vulkan 1.0, and OpenGL 4.5. Its low-profile design makes it suitable for compact workstations.
Benchmarks
| PassMark G3D Mark | 2,863 |
|---|---|
| PassMark G2D Mark | 771 |
| Nero Score AVC encode | 2,031 fps |
Specifications
| Architecture unverified | GCN 2nd Gen |
|---|---|
| GPU chip unverified | Bonaire PRO |
| Process node unverified | 28 nm |
| Shading units unverified | 768 |
| Base clock unverified | 930 MHz |
| Memory size unverified | 4 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 96 GB/s |
| Board power (TDP) unverified | 50 W |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | 4 Mini DisplayPort 1.2a |
| DirectX support unverified | 11.2/12.0 SM 5.0 |
| Vulkan support unverified | 1.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2015-12-01 |
| Release year unverified | 2015 |
| Notes unverified | low profile |
