NVIDIA · 2014
NVIDIA Quadro K4200
The NVIDIA Quadro K4200 is a professional graphics card for workstations, released in 2014 based on the Kepler architecture.
The NVIDIA Quadro K4200 is a professional graphics card released on July 22, 2014, targeting workstation users. It is built on the Kepler architecture using the GK104 GPU chip fabricated on a 28 nm process. The card features 1344 shading units, a base and boost clock of 780 MHz, and 4 GB of GDDR5 memory on a 256-bit bus, delivering a memory bandwidth of 172.8 GB/s. It has a board power (TDP) of 105 W and connects via PCIe 2.0 x16. The card supports DirectX 11.0, Vulkan 1.2, and OpenGL 4.6. Its physical dimensions are 9.5 inches in length.
Specifications
| Architecture unverified | Kepler |
|---|---|
| GPU chip unverified | GK104 |
| Process node unverified | 28 nm |
| Shading units unverified | 1344 |
| Base clock unverified | 780 MHz |
| Boost clock unverified | 780 MHz |
| Memory size unverified | 4 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 172.8 GB/s |
| Board power (TDP) unverified | 105 W |
| Bus interface unverified | PCIe 2.0 x16 |
| DirectX support unverified | 11.0 |
| Vulkan support unverified | 1.2 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2014-07-22 |
| Release year unverified | 2014 |
| Notes unverified | 9.5" Card |
