AMD · 2014
AMD FirePro W8100
The AMD FirePro W8100 is a professional graphics card released in 2014, based on the GCN 2nd generation architecture.
The AMD FirePro W8100 is a professional graphics card released on June 26, 2014. It is built on the GCN 2nd generation architecture with a Hawaii Pro GL GPU manufactured on a 28 nm process. The card features 2560 shading units operating at a base clock of 824 MHz. It is equipped with 8 GB of GDDR5 memory on a 512-bit bus, providing a memory bandwidth of 320 GB/s. The board has a TDP of 220 W and connects via PCIe 3.0 ×16. Display outputs include four DisplayPort connectors and an SDI-Link interface. It supports DirectX 11.2b/12.0, Vulkan 1.0, and OpenGL 4.5. The card also includes ECC RAM support.
Benchmarks
| PassMark G3D Mark | 7,327 |
|---|---|
| PassMark G2D Mark | 759 |
| Geekbench 5 OpenCL | 34,705 |
| Nero Score AVC encode | 1,316 fps |
Specifications
| Architecture unverified | GCN 2nd gen |
|---|---|
| GPU chip unverified | Hawaii Pro GL |
| Process node unverified | 28 nm |
| Shading units unverified | 2560 |
| Base clock unverified | 824 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 512 bit |
| Memory bandwidth unverified | 320 GB/s |
| Board power (TDP) unverified | 220 W |
| Bus interface unverified | PCIe 3.0 ×16 |
| Display outputs unverified | 4 DP, SDI-Link |
| DirectX support unverified | 11.2b/12.0 |
| Vulkan support unverified | 1.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2014-06-26 |
| Release year unverified | 2014 |
| Notes unverified | ECC RAM, 4 DP + SDI-Link |
