NVIDIA · 2014
NVIDIA Quadro K5200
The NVIDIA Quadro K5200 is a professional graphics card released in 2014, based on the Kepler architecture and designed for workstations.
The NVIDIA Quadro K5200 is a professional graphics card released on July 22, 2014, targeting workstation applications. It is built on the Kepler architecture using the GK110B GPU chip manufactured on a 28 nm process. The card features 2304 shading units, a base clock of 650 MHz, and a boost clock of 650 MHz. It is equipped with 8 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 192 GB/s. The board has a TDP of 150 W and connects via PCIe 3.0 x16. It supports DirectX 11.0, Vulkan 1.2, and OpenGL 4.6. The card measures 10.5 inches in length.
Benchmarks
| PassMark G3D Mark | 5,780 |
|---|---|
| PassMark G2D Mark | 501 |
| Geekbench 5 CUDA | 13,735 |
| Geekbench 5 Metal | 8,704 |
| Geekbench 5 OpenCL | 16,029 |
| Geekbench 5 Vulkan | 17,881 |
| Blender Open Data score | 281.2 samples/min |
| Nero Score AVC encode | 972 fps |
Specifications
| Architecture unverified | Kepler |
|---|---|
| GPU chip unverified | GK110B |
| Process node unverified | 28 nm |
| Shading units unverified | 2304 |
| Base clock unverified | 650 MHz |
| Boost clock unverified | 650 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 192 GB/s |
| Board power (TDP) unverified | 150 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 11.0 |
| Vulkan support unverified | 1.2 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2014-07-22 |
| Release year unverified | 2014 |
| Notes unverified | 10.5" Card |
