AMD · 2008
AMD Mobility Radeon HD 3670
The AMD Mobility Radeon HD 3670 is a mobile graphics card released in 2008, based on the TeraScale architecture and 55 nm RV635 chip.
The AMD Mobility Radeon HD 3670 is a mobile graphics card released on January 7, 2008. It is built on the TeraScale architecture using the RV635 GPU chip fabricated on a 55 nm process node. The card features 120 shading units, a base clock of 680 MHz, and supports DirectX 10.1 and OpenGL 2.0 (3.3). Memory configurations include 0.5 GB of DDR2, GDDR3, or GDDR4 over a 128-bit bus, providing a memory bandwidth of 25.6 GB/s. With a board power (TDP) of 30 W, it connects via PCIe ×16 2.0. Additional features include UVD (Universal Video Decoder) and PowerPlay 7.0 power management. This card was designed for use in laptops and other mobile systems.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV635 |
| Process node unverified | 55 nm |
| Shading units unverified | 120 |
| Base clock unverified | 680 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | DDR2, GDDR3, GDDR4 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Board power (TDP) unverified | 30 W |
| Bus interface unverified | PCIe ×16 2.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 2.0 (3.3) |
| Release date unverified | 2008-01-07 |
| Release year unverified | 2008 |
| Notes unverified | UVD, PowerPlay 7.0 |
