AMD · 2010
AMD Mobility Radeon HD 5730
The AMD Mobility Radeon HD 5730 is a mid-range graphics card for laptops, released in 2010 based on the TeraScale 2 architecture.
The AMD Mobility Radeon HD 5730 is a mobile graphics card introduced on January 7, 2010. It is built on the TeraScale 2 architecture using the Redwood (RV 830) GPU chip fabricated on a 40 nm process. The card features 400 shading units and a base clock of 650 MHz. It is equipped with 1 GB of DDR3 or GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 25.6 GB/s. The card supports DirectX 11 and OpenGL 4.4. With a board power (TDP) of 26 W, it is suitable for mainstream laptops. It connects via a PCIe ×16 2.1 interface.
Specifications
| Architecture unverified | TeraScale 2 |
|---|---|
| GPU chip unverified | Redwood (RV 830) |
| Process node unverified | 40 nm |
| Shading units unverified | 400 |
| Base clock unverified | 650 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR3, GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Board power (TDP) unverified | 26 W |
| Bus interface unverified | PCIe ×16 2.1 |
| DirectX support unverified | 11 |
| OpenGL support unverified | 4.4 |
| Release date unverified | 2010-01-07 |
| Release year unverified | 2010 |
