AMD · 2016
AMD Radeon E9550
The AMD Radeon E9550 is a graphics card for embedded systems, released in September 2016. It features the Polaris10 GPU on a 14 nm process.
The AMD Radeon E9550 is a graphics card designed for embedded applications, released in September 2016. It is based on the GCN 4 architecture and uses the Polaris10 GPU chip manufactured on a 14 nm process. The card includes 2304 shading units, with a base clock of 1243 MHz. It comes with 8 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 160 GB/s. The board power (TDP) is rated at 95 W. It connects via a PCIe 3.0 ×16 interface and offers display outputs including DisplayPort and HDMI. The card supports DirectX 12.0, Vulkan 1.0, and OpenGL 4.5. It is available in an MXM Type B form factor with multiple DP and HDMI outputs.
Specifications
| Architecture unverified | GCN 4 |
|---|---|
| GPU chip unverified | Polaris10 |
| Process node unverified | 14 nm |
| Shading units unverified | 2304 |
| Base clock unverified | 1243 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 160 GB/s |
| Board power (TDP) unverified | 95 W |
| Bus interface unverified | PCIe 3.0 ×16 |
| Display outputs unverified | DP, HDMI |
| DirectX support unverified | 12.0 |
| Vulkan support unverified | 1.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2016-09 |
| Release year unverified | 2016 |
| Notes unverified | MXM Type B6× DP/HDMI |
