NVIDIA · 2022
NVIDIA GeForce MX570
The NVIDIA GeForce MX570 is a mobile graphics card released in 2022, based on the Ampere architecture.
The NVIDIA GeForce MX570 is a mobile graphics card released in 2022, built on the Ampere architecture with the GA107 chip on an 8 nm process. It features 2048 shading units, 16 ray tracing cores, and 64 Tensor/AI cores. The card operates at a base clock of 1087 MHz and a boost clock of 1155 MHz. It is equipped with 2 GB of GDDR6 memory on a 64-bit bus, providing a memory bandwidth of 96 GB/s. The board power (TDP) is 15 W, and it uses a PCIe 4.0×4 bus interface. This GPU is designed for thin and light laptops, offering entry-level ray tracing and AI capabilities.
Specifications
| Architecture unverified | Ampere |
|---|---|
| GPU chip unverified | GA107 |
| Process node unverified | 8 nm |
| Shading units unverified | 2048 |
| Ray tracing cores unverified | 16 |
| Tensor / AI cores unverified | 64 |
| Base clock unverified | 1087 MHz |
| Boost clock unverified | 1155 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 96 GB/s |
| Board power (TDP) unverified | 15 W |
| Bus interface unverified | PCIe 4.0×4 |
| Release year unverified | 2022 |
