NVIDIA · 2025
NVIDIA GeForce RTX5090 D V2
The NVIDIA GeForce RTX5090 D V2 is a high-end graphics card based on the Blackwell architecture, released in 2025.
The NVIDIA GeForce RTX5090 D V2 is a graphics card built on the Blackwell architecture with the GB202-240-K1-A1 GPU chip on a 4 nm process. It features 21760 shading units, 170 ray tracing cores, and 680 tensor/AI cores. The card operates at a base clock of 2017 MHz and a boost clock of 2407 MHz. It is equipped with 24 GB of GDDR7 memory on a 384-bit bus, providing a memory bandwidth of 1344.0 GB/s. The board power (TDP) is 575 W, requiring a single 16-pin power connector. The card uses a PCIe 5.0 x16 bus interface and offers display outputs including one HDMI 2.1b and three DisplayPort 2.1a. It supports DirectX 12 Ultimate, Vulkan 1.4, and OpenGL 4.6. The card was released on August 15, 2025 with a launch MSRP of 2299 USD.
Specifications
| Architecture unverified | Blackwell |
|---|---|
| GPU chip unverified | GB202-240-K1-A1 |
| Process node unverified | 4 nm |
| Shading units unverified | 21760 |
| Ray tracing cores unverified | 170 |
| Tensor / AI cores unverified | 680 |
| Base clock unverified | 2017 MHz |
| Boost clock unverified | 2407 MHz |
| Memory size unverified | 24 GB |
| Memory type unverified | GDDR7 |
| Memory bus unverified | 384 bit |
| Memory bandwidth unverified | 1344.0 GB/s |
| Board power (TDP) unverified | 575 W |
| Power connectors unverified | 1x 16-pin |
| Bus interface unverified | PCIe 5.0 x16 |
| Display outputs unverified | 1x HDMI 2.1b, 3x DisplayPort 2.1a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.4 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2025-08-15 |
| Release year unverified | 2025 |
| Launch MSRP unverified | 2299 USD |
