NVIDIA
NVIDIA Quadro FX 540
The NVIDIA Quadro FX 540 is a professional graphics card based on the Curie architecture, designed for workstations.
The NVIDIA Quadro FX 540 is a professional graphics card released by NVIDIA, built on the Curie architecture. It uses the NV43GL GPU chip fabricated on a 90 nm process node. The card features 8 shading units and a base clock of 300 MHz. It comes with 0.125 GB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 8.8 GB/s. The card has a board power (TDP) of 35 W and connects via a PCIe x16 interface. It supports DirectX 9.0c and OpenGL 2.1. This card is intended for use in workstations for professional applications such as CAD and DCC.
Specifications
| Architecture unverified | Curie |
|---|---|
| GPU chip unverified | NV43GL |
| Process node unverified | 90 nm |
| Shading units unverified | 8 |
| Base clock unverified | 300 MHz |
| Memory size unverified | 0.125 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 8.8 GB/s |
| Board power (TDP) unverified | 35 W |
| Bus interface unverified | PCIe x16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
