NVIDIA Quadro FX 550
The NVIDIA Quadro FX 550 is a professional graphics card based on the Curie architecture, designed for workstations.
The NVIDIA Quadro FX 550 is a professional graphics card released by NVIDIA, built on the Curie architecture. It uses the NV43 GPU fabricated on a 110 nm process node. The card features 8 shading units and a base clock of 360 MHz. It is equipped with 0.125 GB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 12.8 GB/s. The board has a TDP of 30 W and connects via a PCIe x16 interface. It supports OpenGL 2.1. This card is intended for use in workstations for CAD and professional visualization applications.
Specifications
| Architecture unverified | Curie |
|---|---|
| GPU chip unverified | NV43 |
| Process node unverified | 110 nm |
| Shading units unverified | 8 |
| Base clock unverified | 360 MHz |
| Memory size unverified | 0.125 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 12.8 GB/s |
| Board power (TDP) unverified | 30 W |
| Bus interface unverified | PCIe x16 |
| OpenGL support unverified | 2.1 |
