AMD · 2007
Radeon HD 2400 PRO
The Radeon HD 2400 PRO is a graphics card released by AMD in 2007, based on the RV610 GPU built on a 65 nm process.
The Radeon HD 2400 PRO is a graphics card from AMD's Radeon HD 2000 series, introduced on June 28, 2007. It utilizes the RV610 GPU manufactured on a 65 nm process node. The card features 40 shading units and a base clock speed of 525 MHz. Memory is provided via DDR2 type with a 64-bit memory bus, resulting in a memory bandwidth of 6.40 GB/s. The card has a board power (TDP) of 20 W. It supports DirectX 10.0 and OpenGL 3.3. The Radeon HD 2400 PRO is available in multiple bus interface variants: PCIe 1.0 ×16, AGP, and PCI. It was designed for entry-level desktop systems and basic multimedia tasks.
Benchmarks
| PassMark G3D Mark | 114 |
|---|---|
| PassMark G2D Mark | 346 |
Specifications
| GPU chip unverified | RV610 |
|---|---|
| Process node unverified | 65 nm |
| Shading units unverified | 40 |
| Base clock unverified | 525 MHz |
| Memory type unverified | DDR2 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 6.40 GB/s |
| Board power (TDP) unverified | 20 W |
| Bus interface unverified | PCIe 1.0 ×16, AGP, PCI |
| DirectX support unverified | 10.0 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2007-06-28 |
| Release year unverified | 2007 |
