ATI · 2005
Radeon X1600 XT
The Radeon X1600 XT is a mid-range graphics card released by ATI in October 2005, based on the RV530 GPU with 12 shading units and 256 MB GDDR3 memory.
The Radeon X1600 XT (ATI) is a mid-range graphics card launched on October 10, 2005, with a suggested retail price of $249. It is built on the R500 architecture using the RV530 GPU fabricated on a 90 nm process. The card features 12 shading units, a base clock of 590 MHz, and 256 MB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 22.08 GB/s. It supports DirectX 9.0c and OpenGL 2.1, and connects via a PCIe ×16 interface. The board power (TDP) is rated at 42 W. This card was positioned for mainstream gaming and multimedia use, compatible with systems featuring a PCIe ×16 slot.
Specifications
| Architecture unverified | R500 |
|---|---|
| GPU chip unverified | RV530 |
| Process node unverified | 90 nm |
| Shading units unverified | 12 |
| Base clock unverified | 590 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 22.08 GB/s |
| Board power (TDP) unverified | 42 W |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2005-10-10 |
| Release year unverified | 2005 |
| Launch MSRP unverified | 249 USD |
