ATI · 2005
Radeon X1300 Pro
The Radeon X1300 Pro is a mid-range graphics card released by ATI in 2005, based on the RV515 GPU and 90 nm process.
The Radeon X1300 Pro (ATI) is a mid-range graphics card launched on October 5, 2005, with an MSRP of $149. It is built on the Radeon R300 architecture using the RV515 GPU fabricated on a 90 nm process. The card features 4 shading units, a base clock of 600 MHz, and 0.256 GB of DDR2 memory on a 128-bit bus, providing a memory bandwidth of 12.8 GB/s. It supports DirectX 9.0c and OpenGL 2.1. The card has a TDP of 31 W and is available in AGP 8× and PCIe ×16 bus interfaces. It is designed for use with compatible motherboards and power supplies of the era.
Specifications
| Architecture unverified | Radeon R300 |
|---|---|
| GPU chip unverified | RV515 |
| Process node unverified | 90 nm |
| Shading units unverified | 4 |
| Base clock unverified | 600 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | DDR2 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 12.8 GB/s |
| Board power (TDP) unverified | 31 W |
| Bus interface unverified | AGP 8×, PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2005-10-05 |
| Release year unverified | 2005 |
| Launch MSRP unverified | 149 USD |
