ATI · 2004
Radeon X800 XT Platinum Edition
The Radeon X800 XT Platinum Edition is a high-end graphics card released by ATI in 2004, featuring the R423 GPU clocked at 520 MHz and 256 MB of GDDR3 memory.
The Radeon X800 XT Platinum Edition is a graphics card from ATI's X800 series, launched on May 5, 2004. It is built on the R423 GPU fabricated with a 130 nm process, with a core clock speed of 520 MHz. The card is equipped with 256 MB of GDDR3 video memory on a 256-bit memory interface, providing a memory bandwidth of 35.84 GB/s. Its thermal design power (TDP) is rated at 88 W. It was positioned as a high-end offering, featuring higher clock speeds than the standard X800 XT, and competed with Nvidia's GeForce 6800 series.
Benchmarks
| PassMark G3D Mark | 81 |
|---|---|
| PassMark G2D Mark | 170 |
Specifications
| GPU chip unverified | R423 |
|---|---|
| Process node unverified | 130 nm |
| Base clock unverified | 520 MHz |
| Memory size unverified | 0.25 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 35.84 GB/s |
| Board power (TDP) unverified | 88 W |
| Release date unverified | 2004-05-05 |
| Release year unverified | 2004 |
