ATI · 2005
Radeon X1600 Pro
The Radeon X1600 Pro is a mid-range graphics card released by ATI in October 2005, based on the RV530 GPU with 12 shading units and 256 MB DDR2 memory.
The Radeon X1600 Pro (ATI) is a mid-range graphics card launched on October 10, 2005, with a launch MSRP of 149 USD. It is built on the TeraScale 2 architecture using the RV530 GPU fabricated on a 90 nm process node. The card features 12 shading units, a base clock of 390 MHz, and 256 MB of DDR2 memory on a 128-bit bus, providing a memory bandwidth of 12.48 GB/s. It supports DirectX 9.0c and OpenGL 2.1. The board power (TDP) is 41 W. The card is available with either an AGP 8× or PCIe ×16 bus interface, making it compatible with a range of motherboards from that era.
Specifications
| Architecture unverified | TeraScale 2 |
|---|---|
| GPU chip unverified | RV530 |
| Process node unverified | 90 nm |
| Shading units unverified | 12 |
| Base clock unverified | 390 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | DDR2 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 12.48 GB/s |
| Board power (TDP) unverified | 41 W |
| Bus interface unverified | AGP 8×, PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2005-10-10 |
| Release year unverified | 2005 |
| Launch MSRP unverified | 149 USD |
