ATI · 2004
Radeon X800 XT
The Radeon X800 XT is a graphics card released by ATI in 2004, based on the R400 architecture and R420 GPU.
The Radeon X800 XT is a graphics card from ATI, released on May 4, 2004. It is built on the R400 architecture using the R420 GPU fabricated on a 130 nm process. The card features 16 shading units and a base clock of 500 MHz. It comes with 0.256 GB of GDDR3 memory on a 256-bit bus, providing a memory bandwidth of 32 GB/s. The board power (TDP) is 86 W. It uses an AGP 8× bus interface and supports DirectX 9.0b and OpenGL 2.0. The Radeon X800 XT succeeded the Radeon 9800 XT and was succeeded by the Radeon X850 XT.
Specifications
| Architecture unverified | R400 |
|---|---|
| GPU chip unverified | R420 |
| Process node unverified | 130 nm |
| Shading units unverified | 16 |
| Base clock unverified | 500 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 32 GB/s |
| Board power (TDP) unverified | 86 W |
| Bus interface unverified | AGP 8× |
| DirectX support unverified | 9.0b |
| OpenGL support unverified | 2.0 |
| Release date unverified | 2004-05-04 |
| Release year unverified | 2004 |
| Successor unverified | Radeon X850 XT |
| Predecessor unverified | Radeon 9800 XT |
