Asus · 2017
Asus EX-A320M-Gaming
The Asus EX-A320M-Gaming is a Micro-ATX motherboard with AMD A320 chipset and AM4 socket, released in 2017.
The Asus EX-A320M-Gaming is a Micro-ATX motherboard based on the AMD A320 chipset, supporting AM4 socket CPUs. It features four DDR4 memory slots with dual-channel support, up to 64 GB maximum capacity. Expansion includes one PCIe 3.0 x16 slot and one PCIe 3.0 x4 open-ended slot. Storage is provided by four SATA ports; no M.2 slots are present. Rear I/O offers two USB 3.0 ports, a Gigabit LAN port, and audio via Realtek ALC887 codec. Wi-Fi is not included. This board is designed for budget gaming builds with AMD Ryzen processors.
Specifications
| Chipset | AMD A320 |
|---|---|
| CPU socket | AM4 |
| Form factor | Micro-ATX |
| Memory slots | 4 |
| Memory type | DDR4 |
| Max memory unverified | 64 GB |
| Memory channels unverified | 2 |
| PCIe slots | 1x PCIe 3.0 x16, 1x PCIe 3.0 x4 (open-ended) |
| M.2 slots | 0 |
| SATA ports | 4 |
| USB ports (rear) | 2x USB 3.0 (rear) |
| Ethernet | 1x Gb LAN |
| Wi-Fi | No |
| Audio codec unverified | Realtek ALC887 |
| Release year unverified | 2017 |
