Intel · 2023
Intel Core i9 13900F
The Intel Core i9 13900F is a desktop processor from Intel's Raptor Lake family, released in 2023. It features 24 cores and 32 threads, with a boost clock up to 5.60 GHz.
The Intel Core i9 13900F is a desktop processor based on the Raptor Lake microarchitecture, manufactured on a 7 nm process. It has 24 cores: 8 performance cores (P-cores) and 16 efficiency cores (E-cores), supporting 32 threads. The base clock is 2.00 GHz, with a maximum boost clock of 5.60 GHz. It includes 32 MB of L2 cache and 36 MB of L3 cache. The processor has a base power of 65 W and a maximum turbo power of 219 W. It supports up to DDR5-5600 MT/s or DDR4-3200 MT/s memory across two channels, but does not support ECC memory. It has no integrated graphics and provides 20 PCIe lanes (PCIe 5.0 and 4.0). The socket is FCLGA1700. The multiplier is locked, preventing overclocking. It supports instruction sets SSE4.1, SSE4.2, and AVX2. The launch MSRP was $524.
Specifications
| Microarchitecture unverified | Raptor Lake |
|---|---|
| Cores | 24 |
| P-cores | 8 |
| E-cores | 16 |
| Threads | 32 |
| Base clock | 2.00 GHz |
| Boost clock | 5.60 GHz |
| L2 cache (total) | 32 MB |
| L3 cache | 36 MB |
| Process node | 7 nm |
| TDP / base power | 65 W |
| Max turbo power | 219 W |
| Socket | FCLGA1700 |
| Memory support | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
| Memory channels | 2 |
| ECC memory support | No |
| Integrated graphics | None |
| PCIe lanes (CPU) | 20 |
| PCIe version | 5.0 and 4.0 |
| Instruction sets | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Unlocked multiplier | No |
| Release date | 2023-01-01 |
| Release year | 2023 |
| Launch MSRP | 524 USD |
