Intel H770
The Intel H770 is a desktop chipset for LGA 1700 sockets, released in 2023. It supports DDR4 and DDR5 memory and offers 24 PCIe lanes (4.0/3.0).
The Intel H770 is a desktop chipset released in 2023, designed for LGA 1700 sockets. It has a TDP of 6 W and supports both DDR4 and DDR5 memory, but not ECC memory. The chipset provides 24 PCIe lanes (version 4.0 and 3.0) and uses DMI 4.0 for communication with the CPU. It includes 8 SATA III ports, 2 USB 3.2 Gen 2x2 ports, 4 USB 3.2 Gen 2 ports, 8 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. There is no Thunderbolt support. Integrated Ethernet MAC and Intel Wi-Fi 6E AX211 are included. Intel Rapid Storage Technology is supported. CPU overclocking is not supported, but memory overclocking (XMP/EXPO) is. The chipset is compatible with Intel Core processors of the 12th, 13th, and 14th generations.
Specifications
| Socket unverified | LGA 1700 |
|---|---|
| Platform | Desktop |
| TDP | 6 W |
| PCIe version | 4.0, 3.0 |
| Total PCIe lanes (chipset) | 24 |
| DMI version | 4.0 |
| Memory support | DDR4, DDR5 |
| ECC memory support | No |
| SATA III ports | 8 |
| USB4 ports | 0 |
| USB 3.2 Gen 2x2 ports | 2 |
| USB 3.2 Gen 2 ports | 4 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Thunderbolt support | No |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wi-Fi 6E AX211 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date | 2023-01-01 |
| Release year | 2023 |
| Launch MSRP | 36 USD |
