Intel R680E
The Intel R680E is a chipset for LGA 1700 motherboards, released in 2022 for Alder Lake platforms.
The Intel R680E is a chipset designed for LGA 1700 sockets, supporting Alder Lake processors. It features a TDP of 6 W and provides 28 PCIe lanes (PCIe 4.0 and 3.0) with DMI 4.0 interface. It supports ECC memory and includes 8 SATA III ports, multiple USB ports (4 USB 3.2 Gen 2x2, 10 USB 3.2 Gen 2, 10 USB 3.2 Gen 1, 14 USB 2.0), integrated Ethernet MAC, and Intel Wi-Fi 6E AX211. It also supports Intel Rapid Storage Technology and vPro, but does not support memory overclocking (XMP/EXPO). The chipset was released in Q1 2022 with an MSRP of $61.
Specifications
| Socket unverified | LGA 1700 |
|---|---|
| Platform unverified | Alder Lake |
| TDP | 6 W |
| PCIe version | 4.0, 3.0 |
| Total PCIe lanes (chipset) | 28 |
| DMI version | 4.0 |
| ECC memory support | Yes |
| SATA III ports | 8 |
| USB 3.2 Gen 2x2 ports | 4 |
| USB 3.2 Gen 2 ports | 10 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wi-Fi 6E AX211(Gig+) |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2022-Q1 |
| Release year | 2022 |
| Launch MSRP | 61 USD |
