Intel W680
The Intel W680 is a 2022 chipset for LGA 1700 desktop platforms, supporting DDR4/DDR5 memory and ECC memory.
The Intel W680 is a chipset released in January 2022 for LGA 1700 desktop platforms. It has a TDP of 6 W and supports both DDR4 and DDR5 memory with ECC memory support. The chipset provides 28 PCIe lanes (PCIe 4.0 and 3.0) and a DMI 4.0 interface to the CPU. It includes 8 SATA III ports, 4 USB 3.2 Gen 2x2 ports, 10 USB 3.2 Gen 2 ports, 10 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. It features an integrated MAC for Ethernet and integrated Intel Wi-Fi 6E AX211. It supports Intel Rapid Storage Technology and vPro, but does not allow CPU overclocking. Memory overclocking via XMP/EXPO is supported. The launch MSRP was $56.
Specifications
| Socket unverified | LGA 1700 |
|---|---|
| Platform | Desktop |
| TDP | 6 W |
| PCIe version | 4.0, 3.0 |
| Total PCIe lanes (chipset) | 28 |
| DMI version | 4.0 |
| Memory support | DDR4, DDR5 |
| ECC memory support | Yes |
| SATA III ports | 8 |
| USB4 ports | 0 |
| USB 3.2 Gen 2x2 ports | 4 |
| USB 3.2 Gen 2 ports | 10 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Thunderbolt support | No |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wi-Fi 6E AX211 |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date | 2022-01 |
| Release year | 2022 |
| Launch MSRP | 56 USD |
