Intel WM690
The Intel WM690 is a chipset for LGA 1700 Alder Lake platforms, released in 2022. It supports DDR4/DDR5 memory, ECC, and offers 28 PCIe lanes.
The Intel WM690 is a chipset designed for Intel's LGA 1700 socket and Alder Lake platform, released in April 2022 with a launch MSRP of $57. It features a TDP of 3.7 W and supports both DDR4 and DDR5 memory across two channels, including ECC memory support. The chipset provides 28 PCIe lanes (PCIe 3.0 and 4.0) and uses a DMI 4.0 interface to connect to the CPU. It includes 8 SATA III ports, multiple USB ports (4 USB 3.2 Gen 2x2, 10 USB 3.2 Gen 2, 10 USB 3.2 Gen 1, and 14 USB 2.0), integrated Ethernet MAC, and integrated Intel Wi-Fi 6E AX211(Gig+). The WM690 supports Intel Rapid Storage Technology and vPro, but does not support memory overclocking (XMP/EXPO). It is intended for use with Alder Lake processors and compatible components.
Specifications
| Socket unverified | LGA 1700 |
|---|---|
| Platform unverified | Alder Lake |
| TDP | 3.7 W |
| PCIe version | 3.0, 4.0 |
| Total PCIe lanes (chipset) | 28 |
| DMI version | 4.0 |
| Memory support unverified | DDR4, DDR5 |
| Memory channels | 2 |
| ECC memory support | Yes |
| SATA III ports | 8 |
| USB 3.2 Gen 2x2 ports | 4 |
| USB 3.2 Gen 2 ports | 10 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wi-Fi 6E AX211(Gig+) |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2022-04-01 |
| Release year | 2022 |
| Launch MSRP | 57 USD |
