AMD · 2007
AMD FireGL V5600
The AMD FireGL V5600 is a professional graphics card released in 2007, based on the TeraScale 1 architecture.
The AMD FireGL V5600 is a professional graphics card released in 2007, built on the TeraScale 1 architecture. It features the R630 GL GPU chip manufactured on a 65 nm process node. The card includes 120 shading units and operates at a base clock of 800 MHz. It is equipped with 0.5 GB of GDDR4 memory on a 128-bit bus, providing a memory bandwidth of 35.2 GB/s. The card supports DirectX 10 and OpenGL 3.3, but does not support Vulkan. It also supports Shader Model 4.0 and APP Stream. The FireGL V5600 uses a PCIe bus interface and is designed for workstation applications.
Specifications
| Architecture unverified | TeraScale 1 |
|---|---|
| GPU chip unverified | R630 GL |
| Process node unverified | 65 nm |
| Shading units unverified | 120 |
| Base clock unverified | 800 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR4 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 35.2 GB/s |
| Bus interface unverified | PCIe |
| DirectX support unverified | 10 |
| Vulkan support unverified | N/A |
| OpenGL support unverified | 3.3 |
| Release year unverified | 2007 |
| Notes unverified | Shader Model 4.0, APP Stream |
