AMD · 2010
AMD FirePro RG220
The AMD FirePro RG220 is a professional graphics card for remote graphics workstations, released in 2010.
The AMD FirePro RG220 is a professional graphics card based on the TeraScale architecture, featuring the RV711 GPU on a 55 nm process. It includes 80 shading units running at 500 MHz and is equipped with 0.5 GB of GDDR3 memory on a 64-bit bus, providing 12.8 GB/s bandwidth. The card has a TDP of 35 W and connects via PCIe 2.0 x16. It supports DirectX 10.1 and OpenGL 3.3. Notably, it offers dual Ethernet ports and a DMS-59 connector for dual DVI-D output, with no VGA host output, making it suitable for remote workstation scenarios.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV711 |
| Process node unverified | 55 nm |
| Shading units unverified | 80 |
| Base clock unverified | 500 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 12.8 GB/s |
| Board power (TDP) unverified | 35 W |
| Bus interface unverified | PCIe 2.0 ×16 |
| Display outputs unverified | Dual Ethernet, DMS-59 for dual DVI-D |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2010-05 |
| Release year unverified | 2010 |
| Notes unverified | Dual Ethernet ports plus DMS-59 for dual DVI-D output (no VGA host output) |
