AMD · 2011
AMD FirePro 2270
The AMD FirePro 2270 is a low-profile graphics card for workstations, released in 2011. It offers dual display output via DMS-59.
The AMD FirePro 2270 is a professional workstation graphics card released on January 31, 2011. It is based on the TeraScale 2 architecture and uses the Cedar GL (RV810) GPU chip manufactured on a 40 nm process. The card features 80 shading units, a base clock of 600 MHz, and 1 GB of GDDR3 memory on a 64-bit bus, providing a memory bandwidth of 9.6 GB/s. It has a low board power (TDP) of 15 W and connects via PCIe 2.1 x1/x16. Display output is provided through a single DMS-59 connector, which supports dual displays using adapters for DisplayPort, DVI-I, or D-sub. The card supports DirectX 11.0 and OpenGL 4.3.
Specifications
| Architecture unverified | TeraScale 2 |
|---|---|
| GPU chip unverified | Cedar GL (RV810) |
| Process node unverified | 40 nm |
| Shading units unverified | 80 |
| Base clock unverified | 600 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 9.6 GB/s |
| Board power (TDP) unverified | 15 W |
| Bus interface unverified | PCIe 2.1 x1/x16 |
| Display outputs unverified | DMS-59 for dual output: DP or DVI-I or D-sub |
| DirectX support unverified | 11.0 |
| OpenGL support unverified | 4.3 |
| Release date unverified | 2011-01-31 |
| Release year unverified | 2011 |
| Notes unverified | DMS-59 for dual output: DP or DVI-I or D-sub |
