AMD · 2010
AMD FirePro 3D V3800
The AMD FirePro 3D V3800 is a workstation graphics card released in 2010. Built on the 40 nm TeraScale 2 architecture, it utilizes the Redwood Pro GL chip.
The AMD FirePro 3D V3800 is a graphics card launched on April 26, 2010. Built on a 40 nm process node, it is based on the TeraScale 2 architecture and is powered by the Redwood Pro GL (RV830) GPU chip. The card features 400 shading units operating at a base clock of 650 MHz. It comes configured with 0.5 GB of GDDR3 memory running on a 64-bit memory bus, providing a total memory bandwidth of 14.4 GB/s. Designed for a PCIe 2.1 ×16 bus interface, the board has a thermal design power (TDP) of 43 W. It supports DirectX 11.0 and OpenGL 4.3 SM5.0, and includes support for UVD2, PowerPlay, and Eyefinity technologies.
Benchmarks
| PassMark G3D Mark | 472 |
|---|---|
| PassMark G2D Mark | 507 |
Specifications
| Architecture unverified | TeraScale 2 |
|---|---|
| GPU chip unverified | Redwood Pro GL (RV830) |
| Process node unverified | 40 nm |
| Shading units unverified | 400 |
| Base clock unverified | 650 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 14.4 GB/s |
| Board power (TDP) unverified | 43 W |
| Bus interface unverified | PCIe 2.1 ×16 |
| DirectX support unverified | 11.0 |
| OpenGL support unverified | 4.3 SM5.0 |
| Release date unverified | 2010-04-26 |
| Release year unverified | 2010 |
| Notes unverified | UVD2, PowerPlay, Eyefinity |
