NVIDIA NVS 4200M
The NVIDIA NVS 4200M is a professional mobile graphics card released in 2010, based on the Fermi 2.0 architecture.
The NVIDIA NVS 4200M is a professional mobile graphics card released in 2010. It is based on the Fermi 2.0 architecture and uses the GF119 GPU chip manufactured on a 40 nm process. The card features 48 shading units, a base clock of 810 MHz, and 1 GB of GDDR3 memory on a 64-bit bus, providing a memory bandwidth of 12.8 GB/s. It supports DirectX 11 and OpenGL 4.5, and connects via PCIe 2.0 x16. With a TDP of 25 W, it is designed for low-power professional applications. The NVS 4200M is derived from the GeForce GT 520M.
Benchmarks
| PassMark G3D Mark | 257 |
|---|---|
| PassMark G2D Mark | 75 |
| Geekbench 5 OpenCL | 1,155 |
| Nero Score AVC encode | 969 fps |
Specifications
| Architecture unverified | Fermi 2.0 |
|---|---|
| GPU chip unverified | GF119 |
| Process node unverified | 40 nm |
| Shading units unverified | 48 |
| Base clock unverified | 810 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 12.8 GB/s |
| Board power (TDP) unverified | 25 W |
| Bus interface unverified | PCIe 2.0 x16 |
| DirectX support unverified | 11 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2010-01-07 |
| Release year unverified | 2010 |
| Notes unverified | based on GT 520M |
