AMD FirePro 3D V5700
The AMD FirePro 3D V5700 is a professional graphics card released in 2008, based on the TeraScale 1 architecture.
The AMD FirePro 3D V5700 is a professional graphics card released on August 8, 2008. It is built on the TeraScale 1 architecture and uses the RV730 XT GPU chip fabricated on a 55 nm process. The card features 320 shading units, a base clock of 700 MHz, and 0.5 GB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 28.8 GB/s. It supports DirectX 10.1 and OpenGL 3.3, and includes UVD2 for video decoding and PowerPlay for power management. The card has a TDP of 58 W and connects via PCIe 2.0 ×16. It is designed for workstation use, compatible with motherboards supporting PCIe 2.0.
Specifications
| Architecture unverified | TeraScale 1 |
|---|---|
| GPU chip unverified | RV730 XT |
| Process node unverified | 55 nm |
| Shading units unverified | 320 |
| Base clock unverified | 700 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 28.8 GB/s |
| Board power (TDP) unverified | 58 W |
| Bus interface unverified | PCIe 2.0 ×16 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2008-08-08 |
| Release year unverified | 2008 |
| Notes unverified | UVD2, PowerPlay |
