NVIDIA NVS 315

The NVIDIA NVS 315 is a professional graphics card released in 2013, based on the Fermi 2.0 architecture with a GF119 GPU.

The NVIDIA NVS 315 is a professional graphics card introduced on March 10, 2013. It is built on the Fermi 2.0 architecture using the GF119 chip at a 40 nm process node. The card features 48 shading units, a base clock of 523 MHz, and 1 GB of DDR3 memory on a 64-bit bus, providing 14 GB/s memory bandwidth. It has a board power (TDP) of 19.5 W and idle power consumption of 7 W. The card uses a PCIe x16 bus interface and outputs via a DMS-59 connector. It supports DirectX 11.0 and OpenGL 4.1, but does not support Vulkan. The NVS 315 is designed for multi-display professional environments, typically used with compatible workstations and motherboards.

Benchmarks

PassMark G3D Mark286
PassMark G2D Mark187
Geekbench 5 OpenCL851
Nero Score AVC encode1,381 fps

About benchmark sources →

Specifications

Architecture unverified Fermi 2.0
GPU chip unverified GF119
Process node unverified 40 nm
Shading units unverified 48
Base clock unverified 523 MHz
Memory size unverified 1 GB
Memory type unverified DDR3
Memory bus unverified 64 bit
Memory bandwidth unverified 14 GB/s
Board power (TDP) unverified 19.5 W
Bus interface unverified PCIe x16
Display outputs unverified DMS-59
DirectX support unverified 11.0
Vulkan support unverified n/a
OpenGL support unverified 4.1
Release date unverified 2013-03-10
Release year unverified 2013
Notes unverified Idle Power Consumption 7 W
