AMD · 2007
AMD Mobility Radeon HD 2400 XT
The AMD Mobility Radeon HD 2400 XT is a mobile graphics card released in 2007, based on the TeraScale architecture with the RV610 chip.
The AMD Mobility Radeon HD 2400 XT is a mobile graphics card released on May 14, 2007. It is built on the TeraScale architecture using the RV610 GPU chip fabricated on a 65 nm process. The card features 40 shading units and a base clock of 600 MHz. It supports up to 0.256 GB of memory, available in DDR2 or GDDR3 types, connected via a 64-bit memory bus, providing a memory bandwidth of 6.4 GB/s. The card uses a PCIe ×16 bus interface and supports DirectX 10.0 and OpenGL 2.0 (with 3.3 compatibility). It includes UVD (Universal Video Decoder) and PowerPlay 7.0 power management technology. This card is intended for use in laptops and other mobile systems.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV610 |
| Process node unverified | 65 nm |
| Shading units unverified | 40 |
| Base clock unverified | 600 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | DDR2, GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 6.4 GB/s |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 10.0 |
| OpenGL support unverified | 2.0 (3.3) |
| Release date unverified | 2007-05-14 |
| Release year unverified | 2007 |
| Notes unverified | UVD, PowerPlay 7.0 |
