NVIDIA Quadro FX Go 1400
The NVIDIA Quadro FX Go 1400 is a mobile professional graphics card released in 2005, based on the Curie architecture.
The NVIDIA Quadro FX Go 1400 is a mobile workstation graphics card released on February 25, 2005. It is built on the Curie architecture using the NV41 GLM GPU chip fabricated on a 130 nm process. The card features 12 shading units, a base clock of 275 MHz, and 0.256 GB of DDR memory on a 256-bit bus, providing a memory bandwidth of 18.9 GB/s. It supports DirectX 9.0 and OpenGL 2.1, and uses a PCIe bus interface. Notably, it is the last chip designated as a Quadro FX Go and transitions from AGP 8x to PCIe. The core configuration is likely 12:5:12:12, derived from the GeForce Go 6800.
Specifications
| Architecture unverified | Curie |
|---|---|
| GPU chip unverified | NV41 GLM |
| Process node unverified | 130 nm |
| Shading units unverified | 12 |
| Base clock unverified | 275 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | DDR |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 18.9 GB/s |
| Bus interface unverified | PCIe |
| DirectX support unverified | 9.0 |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2005-02-25 |
| Release year unverified | 2005 |
| Notes unverified | Last chip designated as a Quadro FX Go, uses PCIe instead of AGP 8x. Core config has been mentioned as either 8:5:8:8 or 12:5:12:12 - the latter is likely since chip is derived from GeForce Go 6800. |
