AMD · 2006
AMD Mobility Radeon X1700
The AMD Mobility Radeon X1700 is a mobile graphics card released in 2006, based on the R500 architecture with the RV535 chip.
The AMD Mobility Radeon X1700 is a mobile graphics card released in 2006. It is based on the R500 architecture and uses the RV535 GPU chip manufactured on a 90 nm process with strained silicon. The card features 5 shading units and a base clock of 475 MHz. It is equipped with 0.256 GB of memory, available in DDR2 or GDDR3 types, on a 128-bit memory bus, providing a memory bandwidth of 11.2 GB/s. The card uses a PCIe ×16 bus interface. It supports DirectX 9.0c and OpenGL 2.0. The Mobility Radeon X1700 was designed for use in laptops and other mobile systems.
Specifications
| Architecture unverified | R500 |
|---|---|
| GPU chip unverified | RV535 |
| Process node unverified | 90 nm |
| Shading units unverified | 5 |
| Base clock unverified | 475 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | DDR2, GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 11.2 GB/s |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.0 |
| Release date unverified | 2006-02-01 |
| Release year unverified | 2006 |
| Notes unverified | strained silicon |
