AMD Mobility Radeon HD 2600 XT
The AMD Mobility Radeon HD 2600 XT is a mobile graphics card released in 2007, based on the TeraScale architecture with the RV630 chip.
The AMD Mobility Radeon HD 2600 XT is a mobile graphics card released on May 14, 2007. It is built on the TeraScale architecture using the RV630 GPU chip fabricated on a 65 nm process. The card features 120 shading units and a base clock of 680 MHz. It is equipped with 0.256 GB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 24 GB/s. The card supports DirectX 10.0 and OpenGL 2.0 (3.3). It uses a PCIe ×16 bus interface and includes UVD (Universal Video Decoder) and PowerPlay 7.0 power management technology.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV630 |
| Process node unverified | 65 nm |
| Shading units unverified | 120 |
| Base clock unverified | 680 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 24 GB/s |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 10.0 |
| OpenGL support unverified | 2.0 (3.3) |
| Release date unverified | 2007-05-14 |
| Release year unverified | 2007 |
| Notes unverified | UVD, PowerPlay 7.0 |
