AMD Mobility Radeon HD 5430
The AMD Mobility Radeon HD 5430 is a low-power mobile graphics card released in 2010, based on the TeraScale 2 architecture.
The AMD Mobility Radeon HD 5430 is a graphics card for laptops, introduced on January 7, 2010. It uses the Cedar GPU chip built on a 40 nm process and features 80 shading units. The card operates at a base clock of 500 MHz with a boost clock of 550 MHz. It is equipped with 1 GB of DDR3 or GDDR3 memory on a 64-bit bus, providing a memory bandwidth of 12.8 GB/s. The card has a low thermal design power (TDP) of 7 W and connects via a PCIe ×16 2.1 interface. It supports DirectX 11 and OpenGL 4.4.
Specifications
| Architecture unverified | TeraScale 2 |
|---|---|
| GPU chip unverified | Cedar |
| Process node unverified | 40 nm |
| Shading units unverified | 80 |
| Base clock unverified | 500 MHz |
| Boost clock unverified | 550 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR3, GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 12.8 GB/s |
| Board power (TDP) unverified | 7 W |
| Bus interface unverified | PCIe ×16 2.1 |
| DirectX support unverified | 11 |
| OpenGL support unverified | 4.4 |
| Release date unverified | 2010-01-07 |
| Release year unverified | 2010 |
