AMD · 2010
AMD Mobility Radeon HD 530v
The AMD Mobility Radeon HD 530v is a mobile graphics card released in 2010, based on the TeraScale architecture and RV710 chip.
The AMD Mobility Radeon HD 530v is a mobile graphics card released on May 5, 2010. It is built on the TeraScale architecture using the RV710 GPU chip fabricated on a 55 nm process node. The card features 80 shading units and a base clock of 500 MHz. It supports DirectX 10.1 and OpenGL 3.3. Memory configuration includes 1 GB of DDR2, DDR3, or GDDR3 memory on a 64-bit bus, providing a memory bandwidth of 9.6 GB/s. The card has a board power (TDP) of 10 W and connects via a PCIe ×16 2.0 interface. It is designed for use in laptops and other mobile systems.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV710 |
| Process node unverified | 55 nm |
| Shading units unverified | 80 |
| Base clock unverified | 500 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR2, DDR3, GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 9.6 GB/s |
| Board power (TDP) unverified | 10 W |
| Bus interface unverified | PCIe ×16 2.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2010-05-05 |
| Release year unverified | 2010 |
