AMD · 2006
AMD Mobility Radeon X1400
The AMD Mobility Radeon X1400 is a mobile graphics card released in 2006, based on the R500 architecture with a 90 nm RV515 chip.
The AMD Mobility Radeon X1400 is a mobile graphics card introduced on January 19, 2006. It is built on the R500 architecture using the RV515 GPU chip fabricated on a 90 nm process. The card features 4 shading units and a base clock of 445 MHz. It is equipped with 0.128 GB of memory, which can be either DDR or DDR2 type, connected via a 128-bit memory bus providing a bandwidth of 8 GB/s. The card uses a PCIe ×16 bus interface and supports DirectX 9.0c and OpenGL 2.0. It is designed for use in laptop computers from the 2006 era.
Specifications
| Architecture unverified | R500 |
|---|---|
| GPU chip unverified | RV515 |
| Process node unverified | 90 nm |
| Shading units unverified | 4 |
| Base clock unverified | 445 MHz |
| Memory size unverified | 0.128 GB |
| Memory type unverified | DDR, DDR2 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 8 GB/s |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.0 |
| Release date unverified | 2006-01-19 |
| Release year unverified | 2006 |
